濟南GRC構件作為一種新型的內外墻裝飾材料，有質量輕、防火、隔音、防潮等特點，所以被用在很多建筑行業，在裝修的時候要和墻體進行結合連接，如果連接不好，將會影響整體的效果，那么該如何正確的連接，下面就一起來看看吧。
As a new type of interior and exterior wall decoration material, Jinan GRC component has the characteristics of light weight, fire prevention, sound insulation, moisture resistance, etc., so it is used in many construction industries. When decorating, it should be combined with the wall. If the connection is not good, it will affect the overall effect. So how to connect it correctly? Let's take a look at it together.
GRC構件的正確連接：
Correct connection of GRC components:
1、用膨脹螺栓將組件直接固定在墻上
1. Fix the assembly directly on the wall with expansion bolts
(1)螺栓穿過構件的肋，將構件固定在墻上。3.構件安裝在鋼龍骨上，鋼龍骨與建筑主體結構相連。
(1) The bolt passes through the rib of the member and fixes the member to the wall. 3. The components are installed on the steel keel, which is connected with the main structure of the building.
(2)螺栓通過構件上的預埋件與墻體連接。
(2) The bolt is connected with the wall through the embedded parts on the component.
2、小部件可以粘合到墻壁上
2. Widgets can be glued to walls
(1)構件應安裝在建筑物的主體結構或墻體上。如果墻體是加氣混凝土、空心磚等輕質墻體，需要專門設計可靠的安裝系統。所有連接件和龍骨系統需要采取可靠的防銹措施，并應使用鍍鋅鋼或不銹鋼連接材料。
(1) The components shall be installed on the main structure or wall of the building. If the wall is a lightweight wall such as aerated concrete and hollow bricks, a reliable installation system shall be specially designed. Reliable rust prevention measures shall be taken for all connectors and keel systems, and galvanized steel or stainless steel connection materials shall be used.
(2)構件與墻體的連接點需要距墻體邊緣一定距離(大于10㎝)以防止膨脹螺栓劈裂局部墻體或錨固不充分。
(2) The connection point between the component and the wall shall be a certain distance (more than 10cm) from the wall edge to prevent expansion bolts from splitting the local wall or insufficient anchoring.
(3)需要采用各種連接件、錨固件、龍骨等連接方式，并進行結構計算，滿足自重、風荷載、地震荷載、干濕變形、溫度變形作用下的強度和剛度要求。構件的安裝節點需要考慮GRC構件干濕變形大的特點，允許適當?shù)奈灰埔葬尫艠?gòu)件。
(3) Various connections, anchors, keels and other connection methods shall be adopted, and the structural calculation shall be carried out to meet the strength and stiffness requirements under self weight, wind load, seismic load, dry and wet deformation, and temperature deformation. The installation nodes of components need to consider the characteristics of large dry and wet deformation of GRC components, and allow appropriate displacement to release the components.
(4)變形阻礙引起的內力。一般情況下，不得采用焊接所有部件連接點的安裝方法。
(4) Internal force caused by deformation obstruction. In general, the installation method of welding all component connection points shall not be adopted.
(5)用膨脹螺栓將構件安裝在混凝土梁、柱或剪力墻上時，應考慮鉆孔位置剛好有鋼筋，用雙孔長板避開或連接板，以調整鉆孔位置。
(5) When installing components on concrete beams, columns or shear walls with expansion bolts, it should be considered that there are steel bars at the drilling location, and use double hole long plates to avoid or connect the plates to adjust the drilling location.
GRC構件與墻體連接注意事項
Precautions for connection between GRC components and walls
1、GRC構件與墻體的連接。如果沒有防水要求，可以用水泥砂漿填充;有防水要求的，需要用建筑密封膠或其他防水材料密封。
1. Connection between GRC components and walls. If there is no waterproof requirement, it can be filled with cement mortar; If there is a waterproof requirement, it needs to be sealed with building sealant or other waterproof materials.
2、GRC構件與墻體變化處(如檐口、窗戶、門道、陽臺、雨篷、進水口、墻體突變處、轉角處)的接縫應根據實際情況進行詳細設計。在邊緣處，應特別注意安裝螺栓將墻壁劈開的可能性。因此，應確定GRC水泥構件的位置，以確保安裝螺栓與邊緣保持一定距離。
2. The joints between GRC components and wall changes (such as cornices, windows, doorways, balconies, awnings, water inlets, sudden changes of walls, corners) shall be designed in detail according to the actual situation. At the edge, special attention should be paid to the possibility of installing bolts to split the wall. Therefore, the location of GRC cement components should be determined to ensure that the installation bolts are kept at a certain distance from the edge.
GRC構件和墻體之間的連接方法還有很多種，不同的連接方法可以更好的使兩者之間連接，希望這些方法對你有所幫助哦，有不懂的地方可以隨時來我們網站
http://www.nyqaac.com進行咨詢！
There are many connection methods between GRC components and walls. Different connection methods can better connect the two. I hope these methods will help you. If you don't understand, please come to our website at any time http://www.nyqaac.com Consult!
